Aluminum awning windows feature a pleasant slimline architectural appearance, making them one of the most discreet and elegant window types available. Often chosen for their functional design, awning windows are ideal for locations where furniture or kitchen benches prevent easy access to the window frame. The unique chain winder allows effortless operation without interfering with insect, fly, or security screens.
Another key advantage of the awning window is that it can be left partly open during inclement weather to enable continuous ventilation while effectively blocking out harsh weather elements.
| Category | Specification Options |
|---|---|
| Profiles |
• 6063-T5 high quality thermal break aluminum profiles • 6063-T5 high quality non-thermal break aluminum profiles • PVC/UPVC profiles |
| Glass Options |
• Double tempered glazing: 5+12A+5mm, 6+12A+6mm, etc. • Single tempered glazing: 6mm, 8mm, 10mm, 12mm, etc. • Laminated glazing: 8.76mm, 10.76mm, etc. |
| Hardware |
• German top brand • Australian brand • Premium Chinese brand |
| Screen / Mesh |
• Stainless steel security mesh • Aluminum security mesh • Fiberglass flyscreen • Retractable flyscreen |
| Surface Treatment |
• Powder coating • Anodized • Electrophoresis • Wood Grain finish |
Custom Sizes & Designs: Standard sizes serve as a guide; custom dimensions and designs are available upon request. Windows and doors are crafted to meet your specific architectural requirements.
Profile Colors & Finishing: Available surface treatments include Powder Coating, Electrophoresis, Fluorocarbon Painting, and Wood Grain finishes. Choose from a standard color range or request custom color matching.
Window corners are wrapped with thick corrugated board and secured with protective film.
Products are placed onto heavy-duty iron steel pallets capable of loading up to 2.0 tons (approx. 10-15 window/door units per pallet).
Units are secured to steel pallets with screws and steel bars for maximum stability. Pallets are fully wrapped with protective film against moisture and dust.
Forklifts load pallets into containers. Airbags are inserted in pallet spaces to prevent movement during transit, following strict loading inspection routines.
We supply complete window and door systems (including profiles, hardware, accessories, and glass) as well as finished products ready for installation.
Pricing depends on custom specifications. Please provide: 1) Drawings/window schedules detailing dimensions, quantities, and types; 2) Frame color choice; 3) Glass type, thickness, and color specification.
Standard delivery time is approximately 38 days after deposit receipt and final drawing confirmation.
Glass is pre-installed at the factory based on window dimensions to ensure safe transportation and straightforward onsite installation. Onsite glazing is recommended for oversized units.
A 10-year quality warranty is provided covering frame durability, color resistance, hardware, and functional components under proper operation.
Standard terms are 30% - 50% deposit via T/T with the remaining balance due prior to shipment. Irrevocable L/C at sight is also accepted.
